INDUSTRIAL AIRFLOW EQUIPMENT
The AfterBurner 16 is a high-velocity tube-axial fan developed for applications that need an especially concentrated stream of air, including loading areas, long aisles, fabrication stations, drying work, and targeted ventilation. Its compact pedestal footprint, directional tilt, and high-speed two-stage operation make it practical where focused airflow matters more than broad room circulation.
AfterBurner 16 Tube Axial Fan, 120V single phase, two-stage high-speed operation, pedestal mount, and 9,400 CFM rated airflow.
Product Features
- High-volume directional airflow for demanding work areas
- Built for commercial, agricultural, and industrial circulation needs
- Aims cooling air toward people, equipment, aisles, or production zones
- Rugged configuration designed for practical placement and operation
Quick Specifications
| Weight |
68 lbs |
| Airflow |
9000 CFM |
| Motor |
1200 Watts / 1.6 HP /Direct Drive / Totally Enclosed / 115 Volt / 9.7 Amps |
| Fan Diameter |
16” Diameter / Can Use a Standard 16” Tube |
| Controls |
Single Speed |
| Mobility |
Two wheels and two pads |
| Power Cord |
115 Volt / 12" Cord |
| Tilt |
Down 45 degrees and straight up |
| Drive |
Direct |
| Clearance |
16” Optional swing arm mount for dock doors |
| Blade |
7" steel / Aggressive Pitch / 3300 RPM |
| Optional Swing Arm |
Additional $245, not included |
| Clearance |
9400 CFM |
| Power input |
120V |
| Phase |
Single phase |
| Mounting |
Pedestal stand included |
| Model / SKU |
AFTERBURNER-16 |
Where This Fan Works Best
Best for
Warehouses, fabrication shops, service bays, manufacturing areas, barns, agricultural buildings, loading areas, and other hot or poorly circulated workspaces.
Plan before ordering
Verify ceiling height, mounting structure, electrical service, required coverage, and final fan placement.
Why Buy From AIMS Airflow?
Fan selection helpMatch fan size, airflow, mounting style, and controls to the space.
Installation coordinationCoordinate installation requirements and nationwide project support.
Support after the saleGet help with parts, service questions, and equipment support.
Questions about ceiling height, electrical input, mounting, or coverage? Contact AIMS Airflow before ordering.
Frequently asked questions
How much focused airflow does the AFTERBURNER-16 deliver?
The AFTERBURNER-16 is listed at 9400 CFM. Its tube-axial format concentrates airflow for spot cooling, ventilation, drying, and circulation in targeted work zones.
How is the AFTERBURNER-16 positioned in a work area?
The AFTERBURNER-16 includes pedestal stand included, allowing the fan to be placed where directed airflow is needed. Keep intake and discharge areas clear during use.
The AFTERBURNER-16 includes a pedestal stand, allowing the fan to be placed where directed airflow is needed. What power does the AFTERBURNER-16 require?
The AFTERBURNER-16 is listed for 120V, single phase. Verify the circuit and cord requirements before use.
single-phaseInstallation planning noteVerify electrical requirements, mounting conditions, clearances, and final product configuration with AIMS Airflow before installation.
